UP 4000 Edge Series

As low as $199.00

Only %1 left

SKU

UP-EDGE-APL Series

Software Preinstallation Service

Windows 10 IOT Enterprise 2021 (Preinstallation Service including license) + $47.99

Debian 12 (Preinstallation Service) + $17.99

Ubuntu Pro 24.04 OS w/ Ubuntu Pro License (Preinstallation Service): For Intel® Atom®, Celeron® and Pentium® Processors + $47.99

Qty

Optional

Add to Cart

UP7000/UP 4000/UPS V2/UPC Plus power supply 12V@5A<W/O power cord>
$12.99

Qty:
Add to Cart

UP 4000/ UP 7000 Edge VESA Kit
$15.90

Qty:

Ultra compact edge comupting system

Intel Atom® E3950/ Celeron®N3350/ Pentium® N4200 processor (formely Apollo Lake)

Intel® HD Graphics

Up to 8GB LPDDR4 RAM

TPM 2.0 on board

12V DC-in

Low power consumption

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specification

UP-EDGE-APL03C2F-A10-0432

Product Details
Name	UP 4000 Edge, Celeron N3350, 4GB RAM, 32GB eMMC
SKU	UP-EDGE-APL03C2F-A10-0432

General
Mainboard	UP 4000
Processor	Intel® Celeron® N3350
Graphics	Intel® HD Graphics 500
Memory	4GB
eMMC / Storage	32 GB
FPGA	Lattice
BIOS	UEFI
RTC	Yes
Wake-on-LAN (WoL)	Yes
Watchdog Timer	Yes
PXE	Yes
TPM	TPM2.0 on board
Compatible OS	Microsoft Windows 10 (full), Windows IOT Core Yocto project 3.1 Kernel 5.4 Ubuntu 20.04 Kernel 5.4
Dimension	3.62” x 2.52” x 1.78” (92 x 64 x 45.2 mm)

Display
HDMI	1 (HDMI 1.4b)
Display Port	1 x DP 1.2 via USB TYPE C

I/O
USB	USB 3.2 Gen1 Type A x3 USB 3.2 Gen 1 Type-C x1
Audio	1x Mic in 1x Line out

Connectivity
Ethernet	1x GbE (Realtek RTL8111G-CG)

Power
Power Requirement	12V DC-in @ 5A
Power Supply Type	DC Jack, 5.5-2.1mm /phoenix co-lay
Power Consumption (Typical)	12V @ 1.25A (15Watt)

Environmental & Certification
Cooling	Passive cooling (fanless)
Operating Temperature	32°F ~ 140°F (0°C ~ 60°C)
Storage temperature	-40°F ~ 176°F (-40°C ~ 80°C)
MTBF (Hours)	538,629 hrs @ 30°C
Certification	CE/FCC Class A,RoHS

Package
Net Weight	290 g
Gross Weight	549 g
Package dimension (L x W x H)	173 x 156 x 97 mm
HS Code	8471500000
Country of Origin	Taiwan

Longevity
Longevity	2031

UP-EDGE-APL03P4F-A10-0864

Product Details
Name	UP 4000 Edge, Pentium N4200, 8GB RAM, 64GB eMMC
SKU	UP-EDGE-APL03P4F-A10-0864

General
Mainboard	UP 4000
Processor	Intel® Pentium® N4200
Graphics	Intel® HD Graphics 505
Memory	8GB
eMMC / Storage	64 GB
FPGA	Lattice
BIOS	UEFI
RTC	Yes
Wake-on-LAN (WoL)	Yes
Watchdog Timer	Yes
PXE	Yes
TPM	TPM2.0 on board
Compatible OS	Microsoft Windows 10 (full), Windows IOT Core Yocto project 3.1 Kernel 5.4 Ubuntu 20.04 Kernel 5.4
Dimension	3.62” x 2.52” x 1.78” (92 x 64 x 45.2 mm)

Display
HDMI	1 (HDMI 1.4b)
Display Port	1 x DP 1.2 via USB TYPE C

I/O
USB	USB 3.2 Gen1 Type A x3 USB 3.2 Gen 1 Type-C x1
Audio	1x Mic in 1x Line out

Connectivity
Ethernet	1x GbE (Realtek RTL8111G-CG)

Power
Power Requirement	12V DC-in @ 5A
Power Supply Type	DC Jack, 5.5-2.1mm /phoenix co-lay
Power Consumption (Typical)	12V @ 1.25A (15Watt)

Environmental & Certification
Cooling	Passive cooling (fanless)
Operating Temperature	32°F ~ 140°F (0°C ~ 60°C)
Storage temperature	-40°F ~ 176°F (-40°C ~ 80°C)
MTBF (Hours)	538,629 hrs @ 30°C
Certification	CE/FCC Class A,RoHS

Package
Net Weight	290 g
Gross Weight	549 g
Package dimension (L x W x H)	173 x 156 x 97 mm
HS Code	8471500000
Country of Origin	Taiwan

Longevity
Longevity	2031

UP-EDGE-APL03X7F-A10-0464

Product Details
Name	UP 4000 Edge, Atom E3950, 4GB RAM, 64GB eMMC
SKU	UP-EDGE-APL03X7F-A10-0464

General
Mainboard	UP 4000
Processor	Intel Atom® x7-E3950
Graphics	Intel® HD Graphics 505
Memory	4GB
eMMC / Storage	64 GB
FPGA	Lattice
BIOS	UEFI
RTC	Yes
Wake-on-LAN (WoL)	Yes
Watchdog Timer	Yes
PXE	Yes
TPM	TPM2.0 on board
Compatible OS	Microsoft Windows 10 (full), Windows IOT Core Yocto project 3.1 Kernel 5.4 Ubuntu 20.04 Kernel 5.4
Dimension	3.62” x 2.52” x 1.78” (92 x 64 x 45.2 mm)

Display
HDMI	1 (HDMI 1.4b)
Display Port	1 x DP 1.2 via USB TYPE C

I/O
USB	USB 3.2 Gen1 Type A x3 USB 3.2 Gen 1 Type-C x1
Audio	1x Mic in 1x Line out

Connectivity
Ethernet	1x GbE (Realtek RTL8111G-CG)

Power
Power Requirement	12V DC-in @ 5A
Power Supply Type	DC Jack, 5.5-2.1mm /phoenix co-lay
Power Consumption (Typical)	12V @ 1.25A (15Watt)

Environmental & Certification
Cooling	Passive cooling (fanless)
Operating Temperature	32°F ~ 140°F (0°C ~ 60°C)
Storage temperature	-40°F ~ 176°F (-40°C ~ 80°C)
MTBF (Hours)	538,629 hrs @ 30°C
Certification	CE/FCC Class A,RoHS

Package
Net Weight	290 g
Gross Weight	549 g
Package dimension (L x W x H)	173 x 156 x 97 mm
HS Code	8471500000
Country of Origin	Taiwan

Longevity
Longevity	2031

More Info

Getting Started Guide with UP 4000 on Linux

Downloads

UP 4000 Edge 2D/3D Drawings	N/A	N/A	Download
UP 4000 Edge Manual	N/A	N/A	Download
UP 4000 Edge Test Reports and Certifications	N/A	N/A	Download
UP 4000 Edge Datasheet	N/A	N/A	Download
